An outdoor welding powerhouse, featuring an ability to adapt to various terrains. With 3D vision technology, AI capability, and wireless remote operation, it offers programming-free and teaching-free welding operations that are both flexible and intelligent. Equipped with an RX welding process library, it can autonomously generate precise paths and welding postures, ensuring flawless execution of welding tasks. Optionally available with an all-weather canopy, it is versatile enough to operate in a range of climatic conditions.
36.5KVA
Three-phase five-wire system 3x380V±10%/50Hz
Quick-connect power supply
1550kg
2900mm×1700mm×1750mm
≤0.5mm
≤0.5mm
2000Frames/Second
48V
73ah
DC48V
Track-wheeled
Wireless remote control
1km/h
2010mm (Slight Differences in Selection)
0°C to +45°C (operating); -20°C to +60°C (transport and storage)
≤90% RH (non-condensing)
37.5KVA
Three-phase five-wire system 3x380V±10%/50Hz
Quick-connect power supply
2050kg
3400mm×1700mm×2000mm
≤0.5mm
≤0.5mm
2000Frames/Second
48V
73ah
DC48V
Track-wheeled
Wireless remote control
1km/h
700mm
2010mm (Slight Differences in Selection)
0°C to +45°C (operating); -20°C to +60°C (transport and storage)
≤90% RH (non-condensing)
Workpieces can be placed at will with no need for fixture-based positioning.
Equipped with a power battery and capable of wireless remote-control operation, it offers flexible movement.
Suitable for outdoor operations due to its minimal ground flatness requirement.
The arm’s expanded range accommodates welding of taller workpieces (lift model).
Enables autonomous scanning of workpiece models and extraction of weld seam information without programming or teaching.
Employs voice and gesture commands as substitutes for traditional mouse and keyboard inputs.
